Technical Specifications
Measurement MethodCapacitive (submerged sensor plates)
Accuracy±0.5% of full tank capacity
InstallationTank insertion via drilled port (standard fitting)
OutputRS232, RS485, or analog 4–20 mA
Temp CompensationBuilt-in — auto-corrects for fuel density changes
Operating Temp−40 °C to +85 °C
ProtectionIP68
Fuel TypesDiesel, petrol, AdBlue
Key Features
✓
±0.5% accuracy — detects as little as 0.5 L change in a 100 L tank✓
Temperature compensation corrects for fuel density variation automatically✓
RS232/RS485 integrates directly with Teltonika FMB/FMC series trackers✓
No moving parts — sensor is fully static inside the tank✓
Refuelling confirmation — logs exact volumes added at each stop✓
Fuel theft detection with configurable sensitivity thresholds✓
Compatible with diesel, petrol, and AdBlue tanks✓
Long operational lifespan with no mechanical wearIdeal Use Cases
Frequently Asked Questions
Why choose a capacitive fuel sensor over ultrasonic?
Capacitive probes sit in the fuel and hold 99.5% accuracy with slosh and temperature compensation. Ultrasonic mounts outside the tank and is easier to fit, but is the lower-precision option.
Will a capacitive sensor work on a sloped site?
A standard capacitive probe still reads level; for construction and mining tanks on slopes, pair it with SP BLE 4 tilt compensation.
How small a theft can it detect?
TrackAlways capacitive deployments detect level changes down to 0.5 litres when calibrated on Venus.
Does installation require draining the tank?
In-tank probes need a calibrated hole and sealing. TrackAlways installers handle this at the yard; downtime is typically a few hours per truck, not a multi-day workshop stay.
